Production

PRODUCT SPECIFICATION
PRODUCT SPECIFICATION
HOW WAS IT MADE?
HOW WAS IT MADE?
MINIMUM ORDER QUANTITY
MINIMUM ORDER QUANTITY
PACKAGING AND SHIPPING
PACKAGING AND SHIPPING
STANDARD TERMS AND CONDITIONS OF PURCHASE
STANDARD TERMS AND CONDITIONS OF PURCHASE
Delivery period
Delivery period

HEAT INSULATED PAPER CUP – DIMENSIONS

DW

100/110 – 4 oz

200/250 – 8 oz.

300/350 – 10 oz.

350/400-12 oz

450/500-16 oz.

Capacity cl

10

20

30

35

45

Capacity to brim cl

11

25

35

40

50

Capacity in OZ

4

8

10

12

16

Rim OD +/- 0,15 mm

62

80

85

90

90

Height mm

66

88

103

112

136

Bottom OD mm

 46  58  61  61  58

Cup material specification

schemat-kubekInner paper cup
Cardboard 250 – 300 gr. + 18-20PE

Heat insulated sleeve with creasing.
Cardboard 250 – 280 gr.

Ink for food packaging

Low migration and low-dour sheet-fed offset ink.
Mineral oil-free printing ink.

Printing method on paper cups

Paper cups are customized by offset printing method. This produces high quality, vibrant full-color finishing to the end product. CMYK printing method is most widely used but PANTONE method can also be used upon request by the customer.

Heat-insulation

Specially arranged grooves around the cup prevent the adherence of the outer and inner layers, thus minimising the temperature of the cup’s surface. Our paper cups filled with a hot drink are safe and prevent the risk of burning hands.

Patents:

EU – EP2583913 Thermally insulated cup and insulating cover.
RUS – 113251 Utility models
PL – 220705 Kubek izolowany termicznie oraz osłona izolacyjna do kubka
Design view – Design number 002111443-0001

schemat

Minimum order

Minimum orders start with 100 pieces.

Generally, we produce orders for printing paper cups in 2 – 3 weeks depending on the quantity of the order. We are also able to take an express order, which usually takes about 72 hours. For commercial use, it is most cost – effective to buy more cups at one time (over 5,000). The customer can make their own cost calculation using the calculator on our website and check how  the unit price decreases when the quantity ordered increases.

For orders of 5000 units and more (CMYK) customers can order more than one graphic version, e.g. 2500 cups DL-CG_250 with graphic version 1 + 2500 cups DLCG_250 with graphic version 2. The maximum number of graphic versions depends on the cup volume and is presented in the table below.

100/110 ml 200/250 ml 300/350 ml 350/400 ml 450/ 500 ml
16 Grafik 12 Grafik 12 Grafik 8 Grafik 8 grafik

PACKAGING AND SHIPPING

HEAT INSULATED PAPER CUPS PACKAGES 500 pcs.
  100/110 200/250 300/350
items in a package 20 25 25
packages in a box 25 20 20
items in a box 500 500 500
weight of box kg 3,50 6,04 7,74
dimensions of box cm 40x27x23h 40x35x32h 40x40x40h
HEAT INSULATED PAPER CUPS PACKAGES 1000 pcs.
  100/110 200/250 300/350
weight of box kg 7 13 16
dimensions of box cm 40х27х40h 40x35x64h 80x40x40h

PACKAGING IN PALLET

HEAT INSULATED PAPER CUP
DW 100/110 200/250 300/350 350/400 450/500
items in a
package
40 25 25 25 25
packages in a
box
25 20 20 20 20
items in a box 1000 500 500 500 500
weight of box
kg
6,70 6,04 7,74 9,68 10,74
dimensions of
box cm
40х27х40h 40х35х32h 40х40х40h 40х40х40h 40х40х46h
paper cup in
pallet
32000 15000 15000 15000 9000
boxes in pallet 32 30 24 24 18
pallet sizes cm 120x80x170h 120x80x170h 120x80x170h 120x80x170h 120x80x150h

TERMS AND CONDITIONS FOR COMPLETING PURCHASE ORDERS

Minimum volume of purchase order for paper cups

The minimum purchase order for paper cups with a custom print is 500 units / size.
For orders up to 5000 units cups are printed in CMYK technology. For orders of 5000 units and more we use CMYK or PANTONE.

For orders up to 1000 units we use digital print technology. For orders of 1000 units and more we use offset print.

For orders of 5000 units and more (CMYK) customers can order more than one graphic version, e.g. 2500 cups DL-CG_250 with graphic version 1 + 2500 cups DLCG_250 with graphic version 2. The maximum number of graphic versions depends on the cup volume and is presented in the table below.

100/110 ml 200/250 ml 300/350 ml 350/400 ml 450/ 500 ml
16 Grafik 12 Grafik 12 Grafik 8 Grafik 8 Grafik

Price for the preparation of graphic design.

A single charge for graphic design: PLN 200 net/size.

Additional charge for every subsequent graphic version: PLN 60/ size.
Acceptable tolerance during production: +/- 5%

Requirements for graphic design

The client should provide materials for the design of the cup prepared in Adobe Illustrator, Adobe Acrobat (curves design) or Adobe Photoshop.

Designs prepared by the client on a die-cut of a cup will not be accepted for printing. All designs are prepared by the Vendor based on material provided by and agreed with the client.

File formats

  • Photoshop, Illustrator
  • Digital images CMYK (NOT RGB).
  • File formats .cdr, .psd, .tiff, .eps or .ai
  • Resolution 300 dpi, dimensions up to 100%
  • A file should be created in a rectangular shape, prepared with curves in sizes relevant to the template; the gluing rim for the wrapper, logo or printed text should be considered.

Colours

  • Colours should correspond with CMYK or Pantone®.
  • The use of RGB colours is not recommended (if delivered designs are in RGB colours, the final print quality may not satisfy the client’s expectations).
  • In files for purchase orders up to 5000 cups Pantone® colours should be converted to CMYK.

Fonts

  • Conversion to curves – curves cover all font files
  • Target colour – samples
  • Clients can send us a sample printout.
  • Design should be printed on calibrated equipment.

Marketing

We use surplus cups as product samples or photograph them for our portfolio. If you do not accept this, please notify us in writing when placing your purchase order.

Copyrights

The client is responsible for the lawful use of brand colours, names and symbols printed on the cups. When using registered names, symbols, colours or trademarks, the client shall obtain the permission of relevant copyright holders, indicating their company as the client and UNICUP Sp. z o.o. Address: 82-300 Elbląg, ul. Warszawska 54-62 as the producer.

Terms of payment

Express orders completed in 72 hours – 100% prepayment.
Standard orders – 60% prepayment, or if there is a signed agreement – according to the terms of payment specified in this agreement.
The remaining due amount is to be paid not later than 5 business days after the client has received an electronic notification (e-mail) about the product being ready.

Terms and conditions for the completion of purchase orders

Express orders for 500 and 1000 cups are completed within 72 hours (on business days) following the receipt of prepayment and acceptance of design. Acceptance of design should be sent before 12:00 on a business day.

Time of delivery: 24 hours (on business days) in Poland.

Orders up to 30000 units are completed within 4 weeks after the receipt of the design accepted by the client and prepayment.

Orders over 30000 units are completed within 5 weeks.

Express orders for 500 and 1000 cups are completed within 72 hours (on business days) following the receipt of prepayment and acceptance of design. Acceptance of design should be sent before 12:00 on a business day.

Time of delivery: 24 hours (on business days) in Poland.

Orders up to 100 000 units are completed within 4 weeks after the receipt of the design accepted by the client and prepayment.

Orders over 100 000 units are completed within 5 weeks.

We deliver anywhere in the world
